ORIFICE AND FREE JET FLOW
Orifice And Free Jet Flow: MTFM-23
In the Orifice & Free Jet Flow accessory a constant head tank is fed with water from the Hydraulics Bench. The orifice is installed at the base of this tank by means of a special wall fitting, which provides a flush inside surface.
The head is maintained at a constant value by an adjustable over flow and is indicated by a level scale. A series of adjustable probes enable the path followed by the jet to be ascertained.
DEMONSTRATION CAPABILITIES:-
- Establishing the coefficient of velocity for a small orifice.
- Finding the coefficient of discharge for a small orifice with flow under constant head and flow under varying head.
- Comparing the measured trajectory of a jet with that predicted by simple theory of mechanics
- Establishing the coefficient of velocity for a small orifice
- Finding the coefficient of discharge for a small orifice with flow under constant head and flow under varying head
- Comparing the measured trajectory of a jet with that predicted by simple theory of mechanics
TECHNICAL SPECIFICATIONS:-
- Orifice diameters: 3.0 mm and 6.0 mm
- Jet trajectory probes: 8
- Max constant head: 410 mm
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK “keeps the right to modify the content in the product without prior notice.
