AXIAL FAN DEMONSTRATION UNIT
Axial Fan Demonstration Unit: MTFM-104
Axial fan mounted on a stainless steel plinth. Transparent air inlet and air outlet ducts allow the fan construction to be clearly observed. A manually operated adjustable aperture allows the air flow rate to be varied.
A calibrated orifice plate is used on the discharge to measure the air flow rate. Electronic sensors measure the pressure head developed across the fan, the pressure across the orifice plate (and thus the flow rate), the rotational speed of the fan and the air temperature. The fan speed is controlled by modulated DC supply, complete with current sensing to allow the power drawn by the fan to be measured.
The equipment is provided with advanced education and data logging
TECHNICAL SPECIFICATIONS :
- Max flow rate: 38 l/s typical
- Volume : 75 m3
- Gross weight : 90 kg
- Max head : 06 kPa
- Max fan speed : 2,700 rpm
- Motor power rating : 5 W
** Note: The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK ” keeps the right to modify the content in the product without prior notice.
