FREQUENCY COUNTER TRAINER
Frequency Counter Trainer: MTEV-14
Frequency Counter Trainer is an exclusive product designed to demonstrate the fundamental principle and functioning of Frequency Counter. It includes various circuits namely, attenuator circuit, wave shaping circuit, frequency divider circuit, display driver circuit and gate time circuit. All these circuits are incorporated on a single board for study and verification Simple representation of all the circuits explains corresponding functionality in a very easy way to perceive the logics.
FEATURES:-
- Exclusive and Compact design
- Stand-alone operation
- Inbuilt +5V, -12V SMPS
- Diagrammatic representation of Frequency Counter circuit
- Low cost
- Learning material CD
TECHNICAL SPECIFICATIONS:-
- Frequency Range : 20Hz – 30MHz
- Resolution : 10Hz (60KHz Range) 10kHz (30MHz Range)
- Sensitivity : 0.9Volts
- Attenuation : 1 : 1, 1 : 20
- Input Coupling : AC
- Input Impedance : 1MW
- Display : Seven Segment LED Display, 4 digits
- Mains Supply : 90 – 275V, 50Hz
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK “keeps the right to modify the content in the product without prior notice.**
