LISSAJOUS PATTERN TRAINER
Lissajous Pattern Trainer: MTBE-38
Lissajous Pattern Trainer is a unique product designed to explain the measurement of unknown frequency, phase difference and resonance frequency using Lissajous Pattern. It includes two sine wave generators for ease of operation. Cathode Ray Oscilloscope is one of the most versatile and widely used electronic instruments useful in measuring wave parameters such as time period, frequency and voltage. Lissajous patterns are formed on the CRO screen when two signals are provided simultaneously on channel X & Y in XY mode. The result of these patterns helps in analyzing signal parameters.
FEATURES:-
- Inbuilt Sine wave Generators
- Unique and compact design
- E-Manual
- Two year warranty
SCOPE OF LEARNING:-
- Study of Lissajous figures
- Unknown frequency calculation using Lissajous figures
- RLC resonance frequency calculation using Lissajous figures
- Phase Difference calculation using Lissajous figures.
TECHNICAL SPECIFICATIONS:-
- Mains Supply : 230V±10%, 50Hz
- Inbuilt DC Supply : +12 V, 500 mA
- Signal Generators
- Frequency : 10 Hz to 100 kHz
- Amplitude : 0 to 5Vpp
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
