INTERCONNECTION OF TWO PORT NETWORKS
Interconnection of Two Port Networks: MTBE-31
Interconnection of Two Port Networks has been designed specifically to demonstrate the importance of Interconnection of Two Port Networks. It can be used as a stand-alone unit with inbuilt DC power supply. With this product, we can calculate various parameters like Z, Y and ABCD under series, parallel and cascade connection of Two Port Networks. It can be performed in a sequential manner and correspondingly it illustrates the phenomenon of Loading Effect. Various scope of learning makes the subject Study complete and interesting.
FEATURES:-
- Exclusive and Compact design
- Inbuilt +12 V and +5 V DC Power Supplies
- E-Manual
SCOPE OF LEARNING:-
- Study of Cascade Connection of Two Port Networks
- Study of Series Connection of Two Port Networks
- Study of Parallel Connection of Two Port Networks
- Study of Loading Effect with Cascade Connection of Two Port Networks
- Study of Loading Effect with Series Connection of Two Port Networks
- Study of Loading Effect with Parallel Connection of Two Port Networks
TECHNICAL SPECIFICATIONS:-
- Mains Supply : 230 V ±10%, 50 Hz
- DC Power Supply : +12 V, +5 V
** Note:-The content of the product and specification are subject to change without prior notice for continuous improvement. Images shown are for representation purpose only. “MICROTEKNIK” keeps the right to modify the content in the product without prior notice.
