Laminar Air Flow Cabinets works on laminar flow principle involves double filtration of air through coarse Pre Filters (upto 5 microns) and Hepa filters (down to 0.3 microns) for filtration of Biological & Particulate contaminants. A constant uni-directional air flows either Horizontally or Vertically, is drawn from atmosphere and passed through pre and Hepa filters on to the work surface. Fabricated out of reinforced pest and weather resistant Duro-board which is clad in from outside in laminated sheet and inner exposed areas are finished in Epoxy paint. Table top stainless steel sheet. Side panels are fixed and made of clear plexiglass. Front door is folding & made of clear plexiglass.
DOP tested as per Standard BS: 2831 with efficiency 90% down to 5 microns. Made of Washable synthetic material.
Made of Microglass fibre with corrugated aluminium foil separators. DOP tested as per US Standard 209B. Efficiency 99.97% down to 0.3 microns.
Assembly of AU or equivalent motor workable on 220V AC 50Hz single phase, dynamically balanced blowers making the unit least vibrant with minimum noise level.
Available in following sizes :-
Working Chamber: 2 x 2 x 2′
Working Chamber: 3 x 2 x 2′
Working Chamber: 4 x 2 x 2′
Working Chamber: 6 x 2 x 2′
Working Chamber: 8 x 2 x 2′
The K-System encompasses the specialist requirement of ocyte, sperm and embryo handling during procedures in both animal and human reproduction. The K-system is often built into a Laminar Flow Cabinet. The utensils are warmed by the heating of part of the table plate of the cabinet.
The transmitted light source and the regulation transformer for the stereo microscope are located under the stainless steel table plate, with a window for transmitted light built into the table plate.
